PCB Mount Female Audio Connector DIP Stereo Headphone Jack

Rs. 15
B384,TMD500,Th100,KRT0
In stock
+

PCB Mount Female Audio Connector DIP Stereo Headphone Jack
3.5mm Stereo Jack Socket Chassis with nut PCB Panel Mount Chassis adapter

Specifications:

  1. Size : 1.7 x 1.1 x 0.9cm / 0.67″ x 0.43″ x 0.35″(L*W*H);
  2. Color : Silver Tone, Black
  3. Jack Connection: Female
  4. Contact Resistance: =0.03O
  5. Insulation Resistance: =100MO
  6. Withstand Voltage: AC500V(50Hz)/min
  7. Temperature Range: -40~ 55
  8. Rated Load: DC 30V 0.5A
  9. Insertion and Extraction Force: 3~20N
  10. Lift: 5000 times
  11. 3.5mm DIP phone jack used for mobile phone,MP3/MP4 player, other electronical equipment.

Package includes:

  • 1x  PCB-mount Audio female socket
