UNI T True RMS Digital Multimeter UT139S

UNI-T
Rs. 6,325
TMD1,Th6,KRT
In stock
+

Description

UT139 series are CAT III 600V digital multimeters designed for electricians. UNI-T UT139S RMS multimeter, its NCV feature can effectively check the electrical status through measuring EM field intensity. The new UT139S model meter includes special features such as LoZ (ACV) for measuring voltage. UT-139S RMS DMM has a built-in 31-segment analog bar that also gives electricians a better visual representation of measurement results. This smart electrical multimeter is built with a black EBTN display and it is a perfect meter for working in dark environments. This meter is easy to use. Small in size. Digital display panel.

Features Of UNI-T Precision Digital Multimeter UT-139S:

  • The UT139 series are CAT III 600V digital multimeters designed for electricians
  • Its NCV feature can effectively check the electrical status through measuring EM field intensity
  • The new UT139E/S models include special features such as LoZ (ACV) for measuring‘ghost’ voltage
  • Its built-in 31-segment analog bar also gives electricians a better visual representation of measurement results
  • UT139S is built with a black EBTN display and it is a perfect meter for working in dark environments
  • True RMS
  • Auto and manual range selectable
  • LPF (low pass filter) function
  • LoZ (low impedance input) function
  • 31-segment analog bar graph
  • Diode, duty ratio, and continuity buzzer

Specifications Of AC/DC Current Voltage Tester Meter LoZ/LPF UT139S:

  1. DC voltage (V): 600V  ±(0.5%+2)
  2. AC voltage (V): 600V  ±(0.8%+3)
  3. DC current (A): 10A    ±(0.7%+2)
  4. AC current (A): 10A    ±(1%+3)
  5. Resistance (Ω): 60MΩ  ±(0.8%+2)
  6. Capacitance (F): 99.99mF  ±(4%+5)
  7. Frequency (Hz): 10Hz~10MHz   ±(0.1%+4)
  8. Temperature (°C): -40°C~1000°C  ±(1%+4)
  9. Temperature (°F): -40°F~1832°F  ±(1.5%+5)
  10. Display count: 6000
  11. Auto range/Manual range/True RMS: Yes
  12. Bandwidth (Hz): 45Hz~400Hz
  13. NCV/Continuity buzzer: Yes
  14. Duty cycle: 0.1%~99.9%
  15. Diode: Around 3V
  16. LPF/LoZ (ACV): Yes
  17. Analog bar: Yes
  18. Power: 1.5V battery (R6) x 2
  19. Display: 58mm x 36mm
  20. Product color: Red and grey
  21. Product net weight: 345g
  22. Product size: 170mm x 80mm x 48mm

Package includes:

  • 1 x UNI-T UT139S True RMS Multimeter with Diode and Continuity
  • 2 x Test leads
  • 1 x Temperature probe
